Features

  • Effectively used for long period with no requirement for power supply.
  • Strong attraction gives this tool a powerful lifting ability
  • Compact Size, Light Weight makes it safe and easy to operate.
  • Safety Factor of 3 maintained.
  • Powerful Rare Earth NdFeB magnets used.
  • Safety lock for accidental switch off.

These are used to lift and transport, steel and iron slabs, sheets, rounds for factories, warehouses, small fabrication units, Engineering Units and many more. Turning the manual handle activates or turns off the magnet. Finds a major application near flame cutting and during fabrication job. Used for handling steel plates, blocks, rounds, press molds and die tools loading/unloading in machines.

Rated Capacity Job Size Range
Model No. Flat (Kgs.) Dia (Kgs.) SW    (Kgs.) TFL    (Kgs.) Length Width (Ø)
HXPML01 100 45 4 300 1200 800 40-100
HXPML02 200 90 6 600 1200 800 40-100
HXPML03 300 125 9 900 2000 1200 40-160
HXPML04 500 225 18 1500 2500 1500 40-200
HXPML05 1000 450 43 3000 3000 2000 60-350
HXPML06 2000 900 88 6000 3500 2000 80-400
HXPML07 3000 1350 175 9000 3500 2000 80-400
